Hydraulic Goods Lift

• Capacity
• 500 kg

• Car Dimension
• 1200 mm x 1000 mm

• Control Device
• Other, Push Button / Remote Control

• Door Opening Size
• 900 mm x 2000 mm

• Drive Type
• Other, Hydraulic / Chain Drive

• Hoist Way Size
• 1650 mm x 1500 mm

• Inclination
• Vertical

• Load Capacity
• 500 kg

• Machine Room Size
• Not Required (Machine Room Less)

• Material
• other Sheet, Mild Steel

• Max. Lifting Height
• 6 m

• Max. Lifting Weight
• 500 kg

• Mechanism Type
• Other, Chain / Hydraulic

• Noise Level
• <70 dB

• Overhead Height
• 2200 mm

• Pit Depth
• 150 mm

• Power Supply
• AC, 3 Phase

• Safety Device
• Other, Emergency Stop, Limit Switches, Overload Protection

• Speed
• 4-6 m/min

• Type
• Other, Single Mast Goods Lift

• Usage
• Other, Warehouse, Industrial, Commercial

• Voltage
• 380V / 220V

• Working Temperature
• -5C to +70C

• Capacity
• 500 kg to 2000 kg

• Car Dimension
• Customized as per requirement (e.g. 1500mm x 1500mm)

• Control Device
• Other, Push Button / Remote Control

• Door Opening Size
• As per design

• Drive Type
• Other, Hydraulic / Electric Chain

• Hoist Way Size
• Customized

• Inclination
• 0 (Vertical)

• Load Capacity
• As per customized requirement

• Machine Room Size
• Required / As per model

• Material
• other Sheet, Mild Steel Structure

• Max. Lifting Height
• Up to 18 meters

• Max. Lifting Weight
• Up to 2000 kg

• Mechanism Type
• Other, Hydraulic, Dual Mast

• Noise Level
• < 65 dB

• Overhead Height
• Minimum 2500 mm

• Pit Depth
• 150mm - 300mm

• Power Supply
• Electric

• Safety Device
• Other, Emergency Stop, Limit Switch, Safety Interlock

• Speed
• 3-6 m/min

• Type
• Other, Dual Mast Goods Lift

• Usage
• Other, Warehouse, Factory, Industrial Applications

• Voltage
• 380V/415V, 3 Phase

• Working Temperature
• -10C to +50C

• Capacity
• 1000-5000 kg

• Car Dimension
• 1200x1800 mm (customizable)

• Control Device
• Other, Push Button Type

• Door Opening Size
• 1000x2100 mm

• Drive Type
• Hydraulic

• Hoist Way Size
• 1600x2100 mm

• Inclination
• 0 (Vertical Lift)

• Load Capacity
• 1000-5000 kg

• Machine Room Size
• Not Required (Machine Room-less Design)

• Material
• other Sheet, Mild Steel

• Max. Lifting Height
• Up to 25 meters

• Max. Lifting Weight
• 5000 kg

• Mechanism Type
• Other, Hydraulic Cylinder

• Noise Level
• <65 dB

• Overhead Height
• 3000 mm (approx.)

• Pit Depth
• 400-600 mm

• Power Supply
• Electric

• Safety Device
• Other, Emergency Stop, Overload Protection, Safety Interlock

• Speed
• 0.1-0.3 m/s

• Type
• Other, Center Cylinder Goods Lift

• Usage
• Other, Warehouses, Factories, Logistics

• Voltage
• 220-415 V AC

• Working Temperature
• -10C~50C

• Capacity
• 6-20 persons

• Car Dimension
• 1100 x 1400 mm (customizable)

• Control Device
• Other, Microprocessor Control Panel

• Door Opening Size
• 800 x 2100 mm

• Drive Type
• Hydraulic

• Hoist Way Size
• 1600 x 1700 mm

• Inclination
• 0 (Vertical)

• Load Capacity
• 450 - 1600 kg

• Machine Room Size
• 1500 x 1800 mm

• Material
• other Sheet, Stainless Steel / Mild Steel Cabin

• Max. Lifting Height
• Up to 25 meters

• Max. Lifting Weight
• Up to 2000 kg

• Mechanism Type
• Other, Direct Plunger / Roped Hydraulic

• Noise Level
• < 55 dB

• Overhead Height
• 3800 mm minimum

• Pit Depth
• 1200 mm minimum

• Power Supply
• Three Phase, 50/60 Hz

• Safety Device
• Other, Automatic Rescue Device, Overload Sensor, Emergency Stop

• Speed
• 0.3 - 1.0 m/s

• Type
• Other, Passenger Lift

• Usage
• Other, Residential, Commercial, Hotels, Hospitals

• Voltage
• 220-415V

• Working Temperature
• -10C to 60C
